Interface Command Summary continued

Command Description
Set cutout to be reset
automatically
Serial Interface Menu
Read serial sample setting
Set serial sampling setting to n
seconds
Set serial duplex mode:
Set serial duplex mode to full
Set serial duplex mode to half
Set serial linefeed mode:
Set serial linefeed mode to on
Set serial linefeed mode to off
Calibration Menu
Read C0 calibration parameter
Set C0 calibration parameter to n *c0=n
Read CG calibration parameter
Set CG calibration parameter to n
Read low set-point limit value
Set low set-point limit to n
Read high set-point limit value
Set high set-point limit to n
Miscellaneous (not on menus)
Read firmware version number
Read structure of all commands
Read Heater
Set Heater
Set heater to low
Set heater to high
Legend:
Note:
Command Command
Format Example
cm[ode]=a[uto] cm=a
sa[mple] sa
sa[mple]=n sa=0
du[plex]=f[ull]/h[alf]
du[plex]=f[ull] du=f
du[plex]=h[alf] du=h
lf[eed]=on/of[f]
lf[eed]=on lf=on
lf[eed]=of[f] lf=of
*c0 *c0
*c0=0
*cg *cg
*cg=n *cg-156.25
*tl[ow] *tl
*tl[ow]=n *tl=-80
*th[igh] *th
*th[igh]=n *th=205
*ver[sion] *ver
h[elp] h
f1 f1
f1=1/0 (1=high, 0=low)
f1= n
f1=0
f1= n f1=1
[] Optional Command data
{} Returns either information
n Numeric data supplied by user
9 Numeric data returned to user
x Character data returned to user
When DUPLEX is set to FULL and a command is sent to READ, the command is returned followed by a
carriage return and linefeed. Then the value is returned as indicated in the RETURNED column.
10 Digital Communication Interface
Returned
Returned Example
sa: 9 sa: 1
b0: 9 b0: 0
bg: 999.99 bg: 156.25
tl: 999 tl: –80
th: 999 th: 205
ver.9999,9.99 ver.2100,3.56
list of commands
f1:9 f1:1

Power Control Functions

Acceptable
Values
0 to 4000
FULL or HALF
ON or OFF
–999.9 to 999.9
–999.9 to 999.9
–999.9 to 999.9
–999.9 to 999.9
0 or 1
