The baud rate of the bath serial communications may be programmed to
300,600,1200, or 2400 BAUD. Use "UP" or "DOWN" to change the baud rate
value.
New baud rate
2400 b
Press "SET" to set the baud rate to the new value or "EXIT" to abort the opera-
tion and skip to the next parameter in the menu.

Sample Period

The sample period is the next parameter in the serial interface parameter menu.
The sample period is the time period in seconds between temperature measure-
ments transmitted from the serial interface. If the sample rate is set to 5, the
bath transmits the current measurement over the serial interface approximately
every five seconds. The automatic sampling is disabled with a sample period of
0. The sample period is indicated by,
SAmPLE Serial sample period parameter
Press "SET" to choose to set the sample period. The current sample period
value is displayed.
Current sample period (seconds)
SA= 1
Adjust the value with "UP" or "DOWN" and then use "SET" to set the sample
rate to the displayed value.
New sample period
SA= 60

Duplex Mode

The next parameter is the duplex mode. The duplex mode may be set to full du-
plex or half duplex. With full duplex any commands received by the bath via
the serial interface are immediately echoed or transmitted back to the device of
origin. With half duplex the commands are executed but not echoed. The du-
plex mode parameter is indicated by,
dUPL Serial duplex mode parameter
Press "SET" to access the mode setting.
dUP=FULL Current duplex mode setting
The mode may be changed using "UP" or "DOWN" and pressing "SET".
New duplex mode setting
dUP=HALF
