Press "UP" to enter the menu. The operating parameters menu contains the
cutout reset mode setting.
9.11.1

Cutout Reset Mode

The cutout reset mode determines whether the cutout resets automatically when
the bath temperature drops to a safe value or must be manually reset by the
operator.
The parameter is indicated by,
Press "SET" to access the parameter setting. Normally the cutout is set for
manual mode.
Cto=rSt
To change to automatic reset mode press "UP" and then "SET".
Cto=Auto
9.12

Serial Interface Parameters

The serial RS-232 interface parameters menu is indicated by,
SErIAL
The serial interface parameters menu contains parameters which determine the
operation of the serial interface. These controls only apply to baths fitted with
the serial interface. The parameters in the menu are — BAUD rate, sample pe-
riod, duplex mode, and linefeed.
9.12.1

Baud Rate

The baud rate is the first parameter in the menu. The baud rate setting deter-
mines the serial communications transmission rate.
The baud rate parameter is indicated by,
BAUd
Press "SET" to choose to set the baud rate. The current baud rate value will
then be displayed.
1200 b
Cutout reset mode parameter
Cutout set for manual reset
Cutout set for automatic reset
Serial RS-232 interface parameters menu
Serial BAUD rate parameter
Current baud rate
