9 Operation
9.1

Safety measures during normal operation

–
Safety devices must not be removed or disabled while the measuring system is in
operation.
–
Operating personnel must ensure that no unauthorized persons are in the measuring
system's work area.
Carry out the following inspection activities every day:
–
Inspect the measuring system for externally visible damage.
9.2 Measuring the suspension
9.2.1 Measuring the wheel loads
The SetupWizzard software is required to measure wheel loads. Start it as described above
and establish the connection between the netbook and the measuring platforms. The
current measured
The measured values can be displayed in both „kg" and „lbs". In addition, the distribution
of the wheel loads can also be displayed in „%". Select the desired unit in the upper left
section of the display window.
46
value is then displayed on the software user
CP Tech GmbH
Contents
interface.
