You can charge the accumulators of the platform and connect the optional CAN charger
via the charging/communication jack.
The accumulator compartment accommodates the two „eneloop AA" accumulators, which
you can remove, charge or replace if necessary. Always ensure that the accumulators are
inserted correctly.
NOTE
You can connect external measuring sensors via the two sensor connections on the front,
right-hand side of the platform. The connection sequence is irrelevant, as the platform
electronics automatically recognize the connected sensor and process the data
accordingly.
7.3.2 Pairing the measuring platform
A radio connection to the PC is absolutely necessary in order to use the measuring
platforms. For this purpose, the measuring platforms must be „paired" under Windows. This
procedure must be performed once for each platform and does not need to be repeated
afterwards.
To pair the measuring platform with a computer, first start the pairing mode of the platform.
To do this, press the button for 5 seconds. After activating the pairing mode, the flashing
code of the LED on the button changes (3x flashing, 1s repeat time). The pairing mode is
automatically terminated after 60 seconds for safety reasons.
Then select the command „Add device" under Windows. („Start" → „Control Panel" →
„Devices and printers" → „Add device") Windows now searches for all possible devices to
pair in the vicinity. Now select the desired measuring platform from the list; the number or
MAC address of the platform can be found on the sticker on the rear of the measuring
platform.
Finally, the correct connection must be confirmed; to do so, the displayed code must always
be confirmed with „Yes". If an older Windows version is used, a pairing code must be
entered. This code is always „1234".
The measuring platform is now paired with the computer. Perform these steps for all
platforms as needed.
34
–
It is expressly forbidden to use non-rechargeable batteries for operating
the measuring platforms, as these would damage the measuring
electronics of the platforms in the event of an accidental charging process.
–
Only Panasonic eneloop AA accumulators may be used.
–
The platform should never be started without an inserted accumulator.
