Technical Data - CP Autosport SetupWizzard Operating Manual

3.2 Function
The wheel alignment system SetupWizzard in the Easy, Basic and Pro version is only
intended for the measurement of vehicle suspension.
It is predominantly used in motor racing. Special setup wheels with vehicle-specific wheel
adapters are installed at the vehicle. The vehicle is thus lowered onto four measuring
platforms aligned by laser leveling and then secured with positioning templates against
unintentional movement. Using toe lasers, track gauge, camber sensors (inclinometers),
wheel load scales, height measuring modules, and caster measuring, various suspension
measurements can be carried out and, depending on the equipment version,
managed/logged on the netbook.
3.3

Technical data

3.3.1 Measuring platform (System version Pro)
Measuring range
Measuring accuracy
Adjustment range
Accumulator life
Radio transmission 2.4 GHz, range
3.3.2 Camber sensor (System version Pro)
Measuring range
Measuring accuracy
3.3.3 Toe laser
Accumulator life
Power supply
Laser class
Wavelength
3.3.4 Leveling laser (see technical specification user manual)
Accumulator life
Power supply
Laser class
Wavelength
Accuracy
Operating range
Protection class
Operating temperature
20
Contents
0 - 500kg per wheel
approx. 30m
± 1% (based on measuring range)
2x 1.5V AA (Mignon) batteries
4x 1.5 V LR 6 (AA)
505-520mm
±3mm for 10m
-10 to +50°C
CP Tech GmbH
± 0,1%
45mm
15h
± 10°
50h
1
650mm
4,5h
2
25m
IP 54
