8.2 Setting up the measuring system
8.2.1 Installing the setup wheels
First, position your vehicle at the intended measuring location. Lift the vehicle as intended
and exchange the vehicle wheels with the setup wheels of the measuring system.
NOTE
Tighten the setup wheels to the torque of the vehicle wheels. Leave the vehicle jacked up
to position the platforms/measuring platforms under the setup wheels.
8.2.2 Positioning the platforms/measuring platforms
Position the platforms/measuring platforms centrally under the setup wheels. The optional
positioning laser can make work much easier and faster. Make sure that the setup wheel
is precisely centered on the measuring platform, otherwise the measuring accuracy may
be lost.
NOTE
38
Observe the labeling and assignment of the setup wheels.
IMPORTANT:
Always observe the labeling and correct assignment of the setup
wheels and the setup platforms/measuring platforms.
FL = Front Left
FR = Front Right
RL = Rear Left
RR = Rear Right
