Connecting the Power

Installation Instructions
for CE Mark Conformity
Installation
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Division 2 applications may require special
installation. Consult the National Electric Code
for proper installation requirements. The analyzer
must be configured in a suitable equipment
enclosure and installed per the National Electric
Code Article 500 applicable sections which pertain
to the hazardous environment classification in
which the electronics will be used.
Note: The power line is the main disconnect device. However, GE
Panametrics does not provide power supply cords with CSA
Div. 2 hygrometers.
IMPORTANT: For compliance with the EU's Low Voltage Directive
(IEC 1010), this unit requires an external power
disconnect device such as a switch or circuit breaker.
The disconnect device must be marked as such,
clearly visible, directly accessible, and located
within 1.8 m (6 ft) of the unit.
In order to meet CE Mark requirements, you must install
electrical cables as described below.
Note: CE Mark compliance is required only for units used in EEC
countries. To meet CE Mark compliance, shield and ground
the electrical connections as shown in Table 1-1 below.
Table 1-1: Wiring Modifications for CE Compliance
Connection
Connect the shields to the nearest chassis
Input/Output
ground using the shortest run of wire possible.
After all necessary electrical connections are made, seal the unused
cable entry holes with standard conduit plugs or equivalent.
!WARNING!
Caution!
Termination Modification
June 2004
1-19
