IMPORTANT: The instructions in this section apply to entering
reference data for the Delta F oxygen cell only.
Use the steps below to change the reference values for oxygen cell
inputs. (See Figure 2-14 on page 2-26 for a menu map.)
Do not adjust oxygen cell reference data unless
instructed to do so by the factory.
IMPORTANT: You should record this data on the Program
Information List supplied in Appendix A, or on a
separate sheet of paper, and keep it in a safe place.
1. At the Reference Menu (see Table 2-4 on page 2-16), press the
PROBE menu key until the Oxygen Cell Reference Table appears.
See Figure 2-9.

OXYGEN CELL REFERENCE TABLE

HIGH
Ch Zero Span
1
2
3
4
5
6
AutoCal Interval:
Reference Menu
HELP INTERVAL
Figure 2-9: Reference Menu for the Delta F Cell
2. Compare the data on the screen to the reference data printed on the
label placed on the side or front of the unit. If the data is incorrect,
use the following procedure to correct it. If the data is correct, do
one of the following:
•
continue to enter reference values for moisture inputs as
described in A.Entering Moisture Reference Values, page 2-17.
(For other types of probes, see Chapter 2 of the Programming
Manual.)
•
press the DONE menu key until Main Menu appears on the
message line; then refer to Displaying Measurements on
page 2-21. When you exit, the Series 1 automatically calibrates
each channel.
Caution!
LOW
Zero Span
(HH.MM): 01:00
11:15 6/2/00
PROBE DONE
April 2004
2-19
