Measurement Modes And Units For The Series 1 - GE Moisture Image Series 1 Startup Manual

Table 2-5: Measurement Modes and Units for the Series 1
Selected
Meas. Mode
O %= Percent Oxygen default
2
O /ppM = Parts Per Million
2
O /ppB = Parts Per Billion
Oxygen
2
O /µA = Microamps (Diagnostic Mode)
2
O /DVM = Digital Voltmeter (Diagnostic Mode)
2
DP/°C = Dew/Frost Point default
DP/°F = Dew/Frost Point °F
DP/K = Dew/Frost Point K (Kelvin)
%R.H. = Relative Humidity
H/ppMv = Parts per Million of Water by Volume
H/ppMw = Parts per Million of Water by Weight (for liquids only)
H/ppBv = Parts per Billion of Water by Volume
MCF/IG = Pounds of Water per Million Std. Cubic Feet in Ideal Gas
Hygrometry
MCF/NG = Pounds of Water per Million Std. Cubic Feet in Natural Gas
ppMv/NG = Parts Per Million by Volume in Natural Gas
mmHg = Vapor Pressure
Pas = Vapor Pressure
MH = MH* (Diagnostic Mode)
H/DVM = Digital Voltmeter (Diagnostic Mode)
FH = FH* (Diagnostic Mode)
T/°C = Degrees Celsius default
T/°F = Degrees Fahrenheit
Temperature
T/K = Kelvin
T/DVM = Digital Voltmeter (Diagnostic Mode)
PSIg = Pounds per Square Inch Gauge default
Bars = Bars
mbs = Millibars
mm/Hg = Millimeters of Mercury
Pa(g) = Pascal, gauge
Pressure
kPas(g) = KiloPascal, gauge
P/mV = Pressure in millivolts
P/DVM = Digital Voltmeter (Diagnostic Mode)
FP = FP** (Diagnostic Mode)
Aux1/V = Volts default
Auxiliary 1 Aux1/I = Milliamps
Aux1/User = Function (Displays Aux Label)
Aux2/V = Volts default
Auxiliary 2 Aux2/I = Milliamps
Aux2/User = Function (Displays Aux Label)
Volt Reference Vref = Volts default (Diagnostic Mode)
Signal Ground Vgnd = Volts default (Diagnostic Mode)
User
*The MH and FH values are the moisture sensors' response values and are the values that are recorded during calibration.
**The FP value is the MIS Probe's response value for pressure and is the value recorded during calibration.
Initial Setup
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Description of Units
April 2004
Displayed Displayed
Meas. Mode Units
Oxygen %
Oxygen ppm
v
Oxygen ppb
v
Oxygen µA
Oxygen DVM VDC
Dew Point °C
Dew Point °F
Dew Point K
Rel. Humidity %
H O ppm
2 v
H O ppm
2 w
H O ppb
2 v
H O/MMSCF NG lbs
2
H O/MMSCF NG lbs
2
H O (Nat. Gas) ppm
2 v
Vapor Pressure mmHg
Vapor Pressure Pas
H O MH
2
Moisture DVM VDC
MIS Probe FH
Temperature °C
Temperature °F
Temperature K
Temp DVM VDC
Pressure PSIg
Pressure Bars
Pressure mbs
Pressure mmHg
Pressure Pas
Pressure kPas
Pressure mV
Pressure DVM VDC
MIS Probe FP
Aux1 VDC
Aux1 mA
Aux1 (Aux Label) none
AuxX VDC
Aux2 mA
Aux2 (Aux Label) none
Voltage Reference VDC
Signal Ground VDC
2-23
