Activating and Changing
Probes
Verifying Probe
Configuration Data
Initial Setup
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Although the probes are physically connected to the back of the
electronics unit, you must "tell" the electronics what type of
measurements the probe is capable of making. In addition, if you
want to use a constant value rather than a live input, you must "tell"
the electronics that you are using a constant value.
If you do not activate probes, or if you activate them incorrectly, the
No Probe
meter will display
Once you verify and/or change configuration data, refer to Entering
Calibration Data on page 2-11.
IMPORTANT: You should record this data on the Program
Information List supplied in Appendix A, or on a
separate sheet of paper, and keep it in a safe place.
1. Enter the Probe Configuration Menu. (See Figure 2-14 on page 2-
26 for a menu map.) A screen similar to Figure 2-4 appears.
Table 2-1: Entering the Probe Configuration Menu
Press the Main Menu key:
SETTINGS*
SYSTEM
CONFIG
*The Settings Menu will prompt for a passcode (see page 2-5).
SYSTEM CONFIGURATION
Ch O2 HYG
1
2
3
4
5
6

Probe Configuration Menu

HELP TAG
Figure 2-4: Probe Configuration Menu
or other error messages.
To enter the:
Settings Menu
System Settings Menu
Probe Configuration Menu
T P Aux1
ERRORS DONE
April 2004
Aux2
2-7
