Displaying
Measurements
Initial Setup
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
The Series 1 can display measurements in a matrix format or a line
graph. The first time you power it up, the screen will display
measurements in the matrix format. The matrix format has six pages
and each page consists of six boxes as shown in Figure 2-10. You can
program each box to display any measurement for any channel.
1 Dew Point
-18.0 °C
2 Temperature
+35.9 °C
3 H O
2
+0.535 ppm
Main Menu
HELP SELECT
Figure 2-10: Series 1 Matrix Format Screen
Each box in the matrix format is either assigned or unassigned. An
assigned box displays a channel number, measurement mode, units,
and a value. An unassigned box displays no data. See Figure 2-11 on
page 2-22 for examples of each type of box.
4 Oxygen
48.3 ppb
v
5 Pressure
27.10 PSIG
X Unassigned
v
11:35 01/22/2000
SETTINGS OPTIONS
June 2003
pg: 1
2-21
