Dimension
(W x D x H)
LED
LED
Status
Features
Function Meaning
Status Monitoring Rotational speed monitoring, failure alarm
Automatic
Speed-adjustment controlled by temperature
Speed-adjustment
Hot Swapping Hot swapping is supported by the fan tray.

2 Preparation before Installation

2.1 Safety Suggestions
To avoid body injury and equipment damage, please carefully read the safety suggestions before you install
RG-S7808C.
The following safety suggestions do not cover all possible dangers.
2.1.1 General Suggestions
Take security measures (such as wearing an anti-static wrist strap) to ensure safety.
Keep the chassis clean, free from any dust. Please do not place the switch at a damp place to prevent the moisture
from entering the switch.
Make sure the installation site is dry and flat. Take skid-proof measures.
Do not place the equipment in a walking area.
Do not wear loose clothes or any other things that may be caught by the chassis during installation and
maintenance.
Moving or lifting the switch and its components requires team work. Be careful not to get hurt.
2.1.2 Safety Precautions for Removal
RG-S7808C is large and heavy. When you handle them, please pay attention to the following requirements:
Avoid moving the equipment frequently.
Turn off all power supplies and unplug all power cables before you remove the equipment.
At least four people are needed to move the equipment. Do not attempt to move the equipment by one people only.
Keep balance when moving the equipment, and avoid injuring your leg and feet or spraining your waist.
Do not move the equipment by grasping the panel, power supply handle, ventilation holes of the chassis, as they are
not designed to bear the weight of the entire equipment. This may cause damage or even injure you.
Remove all supervisor modules, service modules and power modules before you move the device, to reduce the
chassis weight.
The device must be installed and used in the restricted access location.
2.1.3 Electrical Safety
Please observe local regulations and specifications when performing electrical operations. Relevant operators must
be qualified.
Please carefully check for any potential danger in the working area, for example, ungrounded power supply,
unreliable grounding of the power supply and damp/wet ground or floor.
167.5 mm x 132 mm x 133 mm
Status
Off
Solid green
Meaning
The fan is NOT receiving power or fails.
The fan is operational.
