Flash Memory 512 MB
SDRAM DDRIII 1 GB
36 10/100/1000BASE-T RJ45 ports,
External Port 12 SFP ports (F1-F12 are optical/electrical ports)
4 SFP+ ports
10/100/1000BASE-T
100BASE-FX(1310nm)
100BASE-FX (1550nm)
1000BASE-SX (850nm)
1000BASE-LX (1310nm)
Transmission 1000BASE-LH (1310nm)
Medium 1000BASE-ZX (1550nm)
10GBASE-SR (850nm)
10GBASE-LR (1310nm)
10GBASE-ER (1550nm)
10GBASE-ZR (1550nm)
XG-SFP-AOC1M
XG-SFP-AOC3M
XG-SFP-AOC5M
LED Status, Link/ACT
Hot Swapping Supported
Power Consumption
EMC Standards GB9254-2008 CLASS A
Safety Standards GB4943-2011
Operating
0 to 50° C
Temperature
Storage
-40 to 70° C
Temperature
Operating Humidity 10% to 90% RH (non-condensing)
MTBF 334,000 hours
Weight Net weight: 2.9 kg
Dimensions
412 mm x 390 mm x 40.16 mm
(W x D x H)
1.2.5 M7800C-48GT4XS-EA
Module Appearance
Figure 1-10 Appearance of the M7800C-48GT4XS-EA
External Port
M7800C-48GT4XS-EA module provides 48 10/100/1000BASE-T RJ45 ports and 4 SFP+ ports. The RJ45 ports support
auto-negotiation at 10/100/1000 Mbps, and the SFP+ ports support 10G SFP+ modules, Gigabit SFP modules and hot
swapping. Copper ports do not support half-duplex at 10/100Mbps.
The M7800C-48GT4XS-EA supports 10G SFP+ and Gigabit SFP modules. 10G SFP+ modules cannot be used as
Gigabit SFP modules.
LED
LED
System LED
80W
Identification
Status
on the panel
Off
Status
Solid red
Cat-5 UTP
Multi-mode or single-mode optical fiber, supported by SFP ports
while not supported by SFP+ ports.
Single-mode optical fiber, supported by SFP ports while not
supported by SFP+ ports.
Multi-mode optical fiber
Single-mode optical fiber
Single-mode optical fiber
Single-mode optical fiber
Multi-mode optical fiber
Single-mode optical fiber
Single-mode optical fiber
Single-mode optical fiber
1m SFP+ active optical cable
3m SFP+ active optical cable
5m SFP+ active optical cable
Module
Meaning
The module is NOT receiving power.
The module is faulty.
