Ruijie RG-S7808C Series Hardware Installation And Reference Manual page 23

Off Off
Off Off
Solid green Off
Specifications
Module Model RG-PA3000I-PL
Rated Voltage
100 to 120 VAC, 210 to 240 VAC; 50/60 Hz
Range
Max Voltage
90 to 264 VAC; 47 to 63 Hz
Range
90 to 176 VAC
Max Power
176 to 210 VAC Power: 2500 W
Output
210 to 264 VAC Power: 3000W
Weight Net weight: 2.10 kg
Power Cord
16A power cord
Requirement
Operation Altitude: 4000m max. Storage Altitude: 4000 max.
1.2.13 RG-PA1600I-PL
Module Appearance
Figure 1-18 Appearance of the RG-PA1600I-PL Module
As an AC power module, the RG-PA1600I-PL module provides PoE power input to the M78-PSE module.
External Port
The 3-pin power port for the PoE module is on the M78-PSE module. This port can be connected to standard 16 A power
cord. For more information about M78-PSE, please refer to M78-PSE.
LED
LED
Run Alarm
Solid green Off
Solid red
Solid red
Blinking red
Power: 1200 W
Fault
Off
Output undervoltage
Output overvoltage
Communication fails
Meaning
The module is operational
