Ruijie RG-S7808C Series Hardware Installation And Reference Manual page 25

Off Off
Blinking green Off
Solid green Solid yellow
Solid green Solid yellow
Off Off
Off Off
Off Off
Off Off
Off Off
Solid green Off
Specifications
Module Model RG-PA800I-PL
Rated Voltage
100 to 240VAC; 50/60 Hz
Range
Max Voltage
90 to 264 VAC; 47 to 63 Hz
Range
Max Power 90 to 176 VAC
Output 176 to 264 VAC Power: 800W
Weight Net weight: 1.20kg
Power Cord
10A power cord
Requirement
Operation Altitude: 5,000m max. Storage Altitude: 5,000 max.
1.2.15 M08-FAN
Module Appearance
Figure 1-20 Appearance of the M08-FAN Module
Note:
Fan status LED
Captive screws of fan tray
Composition
The M08-FAN is the fan for service modules and supervisor modules on the RG-S7808C. There is one M08-FAN tray with
two fans and one fan control board. The M08-FAN draws air out to form convection for heat dissipation.
Specifications
Fan Model
Off
Off
Off
Off
Solid red
Solid red
Solid red
Solid red
Solid red
Blinking red
Power: 400W
M08-FAN
There is no power input
The module is in standby mode
Persistent overcurrent.
Temperature alarm
Over-temperature causes power-off
AC is powered off.
Short circuit.
Output undervoltage
Output overvoltage
Communication fails
Fan handle
