Ruijie RG-S7808C Series Hardware Installation And Reference Manual page 24

Off Off
Blinking green Off
Solid green Solid yellow
Solid green Solid yellow
Off Off
Off Off
Off Off
Off Off
Off Off
Solid green Off
Specifications
Module Model RG-PA1600I-PL
Rated Voltage
100 to 120 VAC, 210 to 240 VAC; 50/60 Hz
Range
Max Voltage
90 to 264 VAC; 47 to 63 Hz
Range
Max Power 90 to 176 VAC
Output 176 to 264 VAC Power: 1600 W
Weight Net weight: 1.70 kg
Power Cord
16A power cord
Requirement
Operation Altitude: 4000m max. Storage Altitude: 4000 max.
1.2.14 RG-PA800IF
Module Appearance
Figure 1-19 Appearance of the RG-PA800I-PL Module
As an AC power module, the RG-PA800I-PL module provides PoE power input to the M78-PSE-L module.
External Port
The 3-pin power port for the PoE module is on the M78-PSE module. This port can be connected to standard 10A power
cord. For more information about M78-PSE-L, please refer to M78-PSE-L.
LED
LED
Run Alarm
Solid green Off
Off
Off
Off
Off
Solid red
Solid red
Solid red
Solid red
Solid red
Blinking red
Power: 1000 W
Fault
Off
There is no power input
The module is in standby mode
Persistent overcurrent.
Temperature alarm
Over-temperature causes power-off
AC is powered off.
Short circuit.
Output undervoltage
Output overvoltage
Communication fails
Meaning
The module is operational
