Weight Net weight: 2.8 kg
Dimensions
412 mm x 390 mm x 40.16 mm
(W x D x H)
1.2.8 RG-PA1600I-F
Module Appearance
Figure 1-13 Appearance of the RG-PA1600I-F Module
External port
The RG-PA1600I-F module provides 12 VAC input to the overall system of the RG-S7808C switch. The front panel of the
power supply module provides a 3-pin power port, which can be connected to standard 16A power cord.
LED
LED
AC
Solid green
Off
Solid green
Solid green
Solid green
Solid green
Solid green
Specifications
Module Model RG-PA1600I-F
Rated Voltage
100 to 120 VAC, 200 to 240 VAC; 50/60 Hz
Range
Max Voltage
90 to 264 VAC; 47 to 63 Hz
Range
Max Power 90 to 180 VAC
Output 180 to 264 VAC
High Current DC
192 to 290VDC Power: 1600W
Parameter
Weight Net weight: 2.04 kg
DC/FLT
Solid green
Solid red
Solid red
Solid red
Solid orange
Solid red
Solid red
Power: 1200 W
Power: 1600 W
Meaning
The module is operational
The is no power input or input undervoltage.
Overvoltage.
Overcurrent.
Temperature alarm
Over-temperature fault
PSR on/off
