Ruijie RG-S7808C Series Hardware Installation And Reference Manual page 12

M7800C-24SFP/12GT4XS-EA module provides 12 10/100/1000BASE-T RJ45 ports, 24 SFP ports and 4 SFP+ ports.
RJ45 ports support auto-negotiation. SFP ports 1F-12F are optical/electrical ports. All SEP ports support access
rates of 100/1000M and hot swapping. SFP+ ports support hot swapping, 10G SFP+ modules and Gigabit SFP
modules. Copper ports do not support half-duplex at the rates of 10M/100M.
The M7800C-24SFP/12GT4XS-EA supports 10G SFP+ and Gigabit SFP modules. 10G SFP+ modules cannot be
used as Gigabit SFP modules.
LED
LED
System LED
GT port LED
SFP port LED
SFP+ port LED
Specifications
Model
CPU
BOOTROM
Flash Memory
SDRAM
External Port
Transmission
Medium
LED
Hot Swapping
Power Consumption
Identification
Status
on the panel
Off
Solid red
Status
Blinking green
Solid green
Off
Solid green
Link/ACT
Solid yellow
Blinking
Off
Solid green
Link/ACT
Solid yellow
Blinking
Off
Link/ACT Solid green
Blinking
M7800C-24SFP/12GT4XS-EA
Quad-core CPU, each core with the clock speed of 1.0G
8 MB
512 MB
DDRIII 1 GB
12 10/100/1000BASE-T RJ45 ports,
24 SFP ports (F1-F12 are optical/electrical ports)
4 SFP+ ports
10/100/1000BASE-T
100BASE-FX(1310nm)
100BASE-FX (1550nm)
1000BASE-SX (850nm)
1000BASE-LX (1310nm)
1000BASE-LH (1310nm)
1000BASE-ZX (1550nm)
10GBASE-SR (850nm)
10GBASE-LR (1310nm)
10GBASE-ER (1550nm)
10GBASE-ZR (1550nm)
XG-SFP-AOC1M
XG-SFP-AOC3M
XG-SFP-AOC5M
Status, Link/ACT
Supported
85W
Meaning
The module is NOT receiving power.
The module is faulty.
Initialization is in progress. Continuous blinking indicates
errors.
The module is operational
The port link is NOT connected.
The port is connected at 1000Mbps.
The port is connected at 10/100Mbps.
The port is transmitting and receiving data.
The port link is NOT connected.
The port is connected at 1000Mbps.
The port is connected at 100Mbps.
The port is transmitting and receiving data.
The port link is NOT connected.
The port is connected.
The port is transmitting and receiving data.
Cat-5 UTP
Multi-mode or single-mode optical fiber, supported by SFP ports
while not supported by SFP+ ports.
Single-mode optical fiber, supported by SFP ports while not
supported by SFP+ ports.
Multi-mode optical fiber
Single-mode optical fiber
Single-mode optical fiber
Single-mode optical fiber
Multi-mode optical fiber
Single-mode optical fiber
Single-mode optical fiber
Single-mode optical fiber
1m SFP+ active optical cable
3m SFP+ active optical cable
5m SFP+ active optical cable
