The M7800C-CM adopts the CR2032 lithium battery. The device may explode if a wrong battery model is used.
Used batteries should be properly disposed of.
1.2.2 M7800C-16SFP8XS-EA
Module Appearance
Figure 1-7 Appearance of the M7800C-16SFP8XS-EA
External Port
M7800C-16SFP8XS-EA module provides 16 SFP ports and 8 SFP+ ports. The SFP ports support hot swap and access
rates of 100/1000M. The SFP+ ports support hot swap, 10 SFP+ modules and Gigabit SFP modules.
The M7800C-16SFP8XS-EA supports 10G SFP+ and Gigabit SFP modules. 10G SFP+ modules cannot be used as
Gigabit SFP modules.
LED
LED
System LED
SFP port LED
100BASE-FX(1310nm)
100BASE-FX (1550nm)
1000BASE-SX (850nm)
1000BASE-LX (1310nm)
1000BASE-LH (1310nm)
1000BASE-ZX (1550nm)
10GBASE-SR (850nm)
10GBASE-LR (1310nm)
10GBASE-ER (1550nm)
10GBASE-ZR (1550nm)
XG-SFP-AOC1M
XG-SFP-AOC3M
XG-SFP-AOC5M
Status, Link/ACT
Supported
95W
GB9254-2008 CLASS A
GB4943-2011
0 to 50° C
-40 to 70° C
10% to 90% RH (non-condensing)
305,000 hours
Net weight: 2.8 kg
412 mm x 390 mm x 40.16 mm
Identification
Status
on the panel
Off
Solid red
Status
Blinking green
Solid green
Link/ACT Off
Multi-mode or single-mode optical fiber, supported by SFP ports
while not supported by SFP+ ports.
Single-mode optical fiber, supported by SFP ports while not
supported by SFP+ ports.
Multi-mode optical fiber
Single-mode optical fiber
Single-mode optical fiber
Single-mode optical fiber
Multi-mode optical fiber
Single-mode optical fiber
Single-mode optical fiber
Single-mode optical fiber
1m SFP+ active optical cable
3m SFP+ active optical cable
5m SFP+ active optical cable
Module
Meaning
The module is NOT receiving power.
The module is faulty.
Initialization is in progress. Continuous blinking indicates
errors.
The module is operational
The port link is NOT connected.
