- Page 1 RG-S2900G-E Series Switch Hardware Installation and Reference Guide V1.25...
- Page 2 This document is provided “as is”. The contents of this document are subject to change without any notice. Please obtain the latest information through the Ruijie Networks website. Ruijie Networks endeavors to ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.
- Page 3 It is intended for the users who have some experience in installing and maintaining network hardware. At the same time, it is assumed that the users are already familiar with the related terms and concepts. Obtaining Technical Assistance Ruijie Networks Website: http://www.ruijienetworks.com/ Service Email: service_rj@ruijienetworks.com ...
-
Page 4: Product Overview
(27F and 28F for the S2928G Series, and 51F and 52F for the S2952 Series) also support 2.5 G stack modules. Only the four SFP ports of the RG-S2928G-E V2.00 and RG-S2952G-E V2.00 and later, RG-S2928G-12P and RG-S2928G-24P support 100Base-FX. - Page 5 GE-SFP-STACK1.6M The supported module type may change at any time. Consult us for the detailed change information. Only the four SFP ports of the RG-S2928G-E V2.00 and later support fast Ethernet SFP modules. SFP Port Support 1000Base-X, 1000Base-T and 2.5 G stacked SFP module Only the four SFP ports of the RG-S2928G-E V2.00 and later support 100Base-FX.
- Page 6 Weight Less than 3.5 kg RG-S2928G-E switch is a class A product. In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures. Product Appearance The front panel of the RG-S2928G-E full gigabit Ethernet switch provides one Type-A USB2.0 interface, one RJ45 console port, 24 RJ45 10/100/1000Base-T Ethernet adaptive ports and four SFP ports.
- Page 7 Power cord: 10A power cord Heat Dissipation The RG-S2928G-E full gigabit switch is designed with no fans. To ensure good dissipation, sufficient space (10 cm distance from both sides and the back panel of the chassis) should be reserved for ventilation.
- Page 8 The port is connected. (Note: Only the four SFP ports 25F~28F Blinking The port is transmitting or receiving data. of the RG-S2928G-E V2.00 and later support 100Base-FX.) 1.2 RG-S2952G-E Technical Specifications RG-S2952G-E Model Single-core CPU, clock speed of 600M BOOTROM...
- Page 9 information. Only the four SFP ports of the RG-S2952G-E V2.00 and later support fast Ethernet SFP modules. Support 1000 Base-X, 1000 Base-T, 100 Base-FX and 2.5 G stacked SFP module SFP Port Only the four SFP ports of the RG-S2952G-E V2.00 and later support 100Base-FX. USB Port One Type-A USB2.0 interface ...
- Page 10 RG-S2952G-E switch is a class A product. In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures. Product Appearance The front panel of the RG-S2952G-E full gigabit Ethernet switch provides one Type-A USB2.0 port, one RJ45 console port, 48 RJ45 10/100/1000Base-T adaptive Ethernet ports and four SFP ports.
- Page 11 Figure 1-7 Back Panel of the RG-S2952G-E V2.00 and Later Note: 1. Grounding pole 3. Power cord retention clips 2. Three-hole AC power receptacle 4. Fan outlet Power Supply The RG-S2952G-E can be powered either with AC power or DC power. ...
- Page 12 LED Indicators Indicator Faceplate Marker Status Indication Blinking green The system is being initialized. Solid green The system is in normal operation. Status indicator Status Solid yellow System over-temperature warning. Serious over-temperature, the system will stop Solid red working forcibly by itself. Or the fan fault occurs. The port is NOT connected.
- Page 13 SDRAM DDRII 128MB Supported SFP Type Gigabit Ethernet: MINI-GBIC-SX-MM850 MINI-GBIC-LX-SM1310 MINI-GBIC-LH40-SM1310 MINI-GBIC-ZX50-SM1550 MINI-GBIC-ZX80-SM1550 MINI-GBIC-ZX100-SM1550 Fast Ethernet: FE-SFP-LX-MM1310 FE-SFP-LH15-SM1310 1000 Base-T: Mini-GBIC-GT 2.5 G stack module: GE-SFP-STACK1.6M The supported module type may change at any time. Contact us for the detailed change information.
- Page 14 Storage Humidity 5% RH to 90% RH Support adjustment of fan speed and warning of fan troubles. Supported Temperature Warning EMC Standards GB9254-1998 Safety Standards GB4943-2001 Dimensions (W x D x H) 440 mm x 260 mm x 43.6 mm Weight Less than 4.5 kg RG-S2928G-12P switch is a class A product.
- Page 15 Back Panel Figure 1-11 Back Panel of the RG-S2928G-12P Note: 1. Grounding pole 3. Three-hole AC power receptacle 2. Fan outlet 4. Power cord retention clips Power Supply The RG-S2928G-12P can be powered either with AC power or DC power. ...
- Page 16 When installing the device, sufficient ventilation space (1 U (44.45 mm) distance from the adjacent device) should be reserved for the purpose of heat dissipation. The PoE power supply of the RG-S2928G-12P switch is designed to support the IEEE802.3af and 802.3at standards. It uses Alternative A, that is, uses pins 1&2 and 3&6 to transmit power.
- Page 17 1.4 RG-S2928G-24P Technical Specifications Model RG-S2928G-24P Single-core CPU, clock speed of 600M BOOTROM Flash Memory 128M SDRAM DDRII 128MB Supported SFP Gigabit Ethernet: Type MINI-GBIC-SX-MM850 MINI-GBIC-LX-SM1310 MINI-GBIC-LH40-SM1310 MINI-GBIC-ZX50-SM1550 MINI-GBIC-ZX80-SM1550 MINI-GBIC-ZX100-SM1550 Fast Ethernet: FE-SFP-LX-MM1310 FE-SFP-LH15-SM1310 1000 Base-T: Mini-GBIC-GT ...
-
Page 18: Product Appearance
Maximum PoE/PoE + output power: 370 W Supported. Power Less than 480 W with PoE full load. Consumption Less than 45 W without PoE Working 0º C to 50º C Temperature Storage -40º C to 70º C Temperature Working Humidity 10% RH to 90% RH 5% RH to 90% RH Storage Humidity... - Page 19 Figure 1-14 Front Panel of the RG-S2928G-24P Note: 1. USB2.0 port 6. 100 Base-FX/1000 Base-X SFP port 2. RJ45 console port 7. 100 Base-FX/1000 Base-X SFP/2.5 G stack port 3. System status indicator 8. 100 Base-FX/1000 Base-X SFP/2.5 G stack port indicator 4.
- Page 20 Heat Dissipation The RG-S2928G-24P switch adopts axial fans for heat dissipation, thereby ensuring the device to function normally in the specified environment. Sufficient space (10 cm distance from both sides and the back panel of the chassis) should be reserved for ventilation. Dust the device every three months to avoid blocking the ventilation openings.
- Page 21 Indicator Faceplate Marker Status Indication PoE status indicator 1~24 No PoE power supply. Solid green PoE is operational. Solid yellow Abnormal PoE power supply 100Base-FX/1000Base-X/Stack 25F~28F The port is NOT connected. port indicator Solid green The port is connected. Blinking The port is transmitting and receiving data.
-
Page 22: Preparation Before Installation
2 Preparation before Installation 2.1 Safety Suggestions To avoid personal injury and equipment damage, please carefully read the safety suggestions before you install the RG-S2900G-E series. The following safety suggestions do not cover all possible dangers. 2.1.1 Safety Precautions for Installing the System ... -
Page 23: Installation Site Requirements
Be especially careful for the RG-S2928G-E device. This high-speed forwarding device adopts the fan-free design; therefore, it has high requirement for heat dissipation of the operating environment. -
Page 24: Cleanness Requirements
In an environment with low relative humidity, however, the insulating strip may dry and shrink. Static electricity may occur easily and endanger the circuit on the equipment. In an environment with high temperature, the equipment is subject to even greater harm, as its performance may degrade significantly and various hardware faults may occur. -
Page 25: System Grounding Requirements
The Average refers to the average limit of harmful gas in one week. The Maximum value is the upper limit of the harmful gas measured in one week for up to 30 minutes every day. 2.2.4 EMI During applications, the switch may be subject to external interferences that affect the device through conduction manners such as capacitance coupling, inductive coupling, electromagnetic wave emission, common impedance (including grounding systems), and wires (power cables, signal cables and outgoing transmission cables). -
Page 26: Lightning Resistance Considerations
Figure 2-1 Schematic Diagram of the RG-S2900G-E Grounding 2.2.6 Lightning Resistance Considerations When the AC power cable is imported outdoors and directly connected to the power port of the switch, lightning line bank should be adopted to prevent the switch from being hit by lightning shocks. Usage of the lightning line bank: Connect the mains supply AC cable to the lightning line bank. -
Page 27: Requirements Of Installation Tools
2.3 Requirements of Installation Tools Table 2-4 List of Installation Tools Philips screwdriver, flathead screwdriver, related electric cables and optical cables, bolts, diagonal Common tools pliers, straps Special tools Anti-static tools Meters Multimeter The tool kit is customer supplied. -
Page 28: Product Installation
3 Product Installation Please ensure that you have carefully read the section of “Preparation before Installation”. Make sure that the requirements set forth in section of “Preparation before Installation” have been met. 3.1 Installation Procedure Install the RG-S2900G-E to the rack Connect the system grounding Connect the power supply Connect the external interface cable... -
Page 29: Mounting The Switch In The Rack
During installation, note the following points: Connect the power cables of different colors to the corresponding grounding posts. Ensure that the interface of the power supply cable is well connected to the power interface of the device. The power power cable retention clips cables must be protected using after they are connected to the device. -
Page 30: Checking After Installation
3.4 Checking after Installation Before checking the installation, switch off the power supply so as to avoid any personal injury or damage to the component due to connection errors. Check that the ground line is connected. Check that the cables and power input cables are correctly connected. ... -
Page 31: System Debugging
4 System Debugging 4.1 Establishing the Debugging Environment Establishing the Debugging Environment Connect the PC to the console port of the switch through the console cable, as shown in Figure 4-1. Figure 4-1 Schematic Diagram of the Configuration Environment Connecting the Console Cable ... - Page 32 Enter the name of the new connection and click OK, the interface as shown in Figure 4-3 is displayed. Choose the serial port used currently in the column [use when connecting]. Figure 4-3 After choosing the serial port, click OK to display the serial port parameter setting interface, set the baud rate to 9600, data bit to 8, parity check to none, stop bit to 1 and flow control to none.
-
Page 33: Startup Check
After setting the parameters, click OK to enter the hyper terminal interface. 4.2 Startup Check 4.2.1 Checking before the Device is Powered on The routing host is fully grounded. The power cable is correctly connected. The power supply voltage complies with the requirement of the switch. ... -
Page 34: Maintenance And Troubleshooting
5.2 Troubleshooting Common Faults Symptom Possible Causes Solution Forgetting the A password is manually configured but Please contact Ruijie Networks Customer Service management interface it is forgotten. Department for technical support. login password The status indicator is The power supply module does not... - Page 35 Symptom Possible Causes Solution The serial port The serial port connected to the switch Change the serial port opened by the configuration console has no output does not match that opened by the software to be the one connected to the switch. or outputs illegible configuration software.
-
Page 36: Appendix A: Connectors And Connection Media
Appendix A: Connectors and Connection Media 1000BASE-T/100BASE-TX/10BASE-T Ports The 1000BASE-T/100BASE-TX/10BASE-T is a port that supports adaptation of three rates, and automatic MDI/MDIX Crossover at these three rates. The 1000BASE-T complies with IEEE 802.3ab, and uses the cable of 100-ohm Category-5 or Supper Category-5 UTP or STP, which can be up to 100 m. -
Page 37: Optical Fiber Connection
Straight-Through Crossover Switch Switch Switch Switch 1 IRD + 1 OTD + 1 IRD + 1OTD + 2 IRD - 2 OTD - 2 IRD - 2OTD - 3 OTD + 3 IRD + 3 OTD + 3 IRD + 6 OTD - 6 IRD - 6 OTD -... -
Page 38: Appendix B Mini-Gbic Modules
Appendix B Mini-GBIC Modules We provide appropriate 1000M SFP modules (Mini-GBIC) modules according to the types of interfaces of the switch modules. You can select the SFP module to suit your specific needs. The following models and technical specifications of some 1000M SFP modules are listed for your reference. -
Page 39: Appendix C Site Selection
Appendix C Site Selection The machine room should be at least 5km away from the heavy pollution source such as the smelter, coal mine and thermal power plant, 3.7km away from the medium pollution source such as the chemical industry, rubber industry and electroplating industry, and 2km away from the light pollution source such as the food manufacturer and leather plant.
