Technical data
Classification of mechanical conditions acc. to IEC 60721
Stationary use (IEC 60721-3-3) .............................................................................................................................. 3M4
Transport (IEC 60721-3-2) ..................................................................................................................................... 2M4
Long-term storage (IEC 60721-3-1) .................................................................................................................... 1M12
Connection
Connection type......................................................................................... screw-type terminal or push-wire terminal
Screw-type terminals:
Nominal current....................................................................................................................................................≤ 10 A
Tightening torque...............................................................................................................0.5...0.6 Nm (5...7 lb-in)
Conductor sizes............................................................................................................................................. AWG 24-12
Stripping length ......................................................................................................................................................8 mm
Rigid/flexible........................................................................................................................................... 0.2...2.5 mm
Flexible with ferrules with/without plastic sleeve ..............................................................................0.25...2.5 mm
Multi-conductor rigid ............................................................................................................................ 0.2...1.5 mm
Multi-conductor flexible......................................................................................................................... 0.2...1.5 mm
Multi-conductor flexible with ferrules without plastic sleeve ............................................................0.25...1.5 mm
Multi-conductor flexible with TWIN ferrules with plastic sleeve.......................................................... 0.5...1.5 mm
Push-wire terminals:
Nominal current....................................................................................................................................................≤ 10 A
Conductor sizes............................................................................................................................................. AWG 24-14
Stripping length ....................................................................................................................................................10 mm
Rigid ........................................................................................................................................................ 0.2...2.5 mm
Flexible without ferrules.......................................................................................................................0.75...2.5 mm
Flexible with ferrules with/without plastic sleeve ..............................................................................0.25...2.5 mm
Multi-conductor flexible with TWIN ferrules with plastic sleeve.......................................................... 0.5...1.5 mm
Opening force ........................................................................................................................................................... 50 N
Test opening, diameter .......................................................................................................................................2.1 mm
Wiring of the terminals Up, AK1, GND, AK2 ......... refer to technical data AGH420 under the heading "Connection"
