IsoData data string
String
Alarm message [hexadecimal] (without leading "0x")
The alarms are included in this value with the OR function.
Assignment of the alarms:
0x0002 Device fault
0x0004 Prewarning insulation resistance R
0x0008 Prewarning insulation resistance R
1234;
0x000C Prewarning insulation resistance R
0x0010 Alarm insulation resistance R
0x0020 Alarm insulation resistance R
0x0030 Alarm insulation resistance R
0x0040 Alarm undervoltage U
0x0080 Alarm overvoltage U
0x0100 Message system test
0x0200 Device start with alarm
Update counter, consecutively counts from 0 to 9.
1
It increases with the update of the insulation resistance value.
<CR><LF> String end
isoEV425_D00126_09_M_XXEN/03.2019
Description
at L1/+
F
at L2/-
F
symmetrical
F
n
n
at L1/+
F
at L2/-
F
symmetrical
F
