AT&T Lucent Technologies PARTNER Plus Installation And Use Manual page 100

Problem Possible Cause
1. Ringer equivalents
11. Combina-
are too high for the
tion
Extension
extension.
Problem:
Phone
Does Not
Ring
Properly
2. Optional device
(fax, answering
machine, etc.) is
faulty.
3. Bad adapter or
combination device.
Date, day, and time
12. Phone
do not display
Display
properly.
Does Not
Work
13. Combina- 1. System phone is
plugged into wrong
tion
Extension
jack on bridging
Problem: adapter.
System
2. Wrong cord and
Phone
wrong bridging
Does Not
adapter used to
Work
connect standard
phone.
C-6 Maintenance and Customer Support
Do This
If this is a combination
extension (two devices,) be
sure the total of their Ringer
Equivlance Numbers
(REN) does not exceed
20. (See page 2-7.) If it
exceeds 20, unplug one of
the devices.
Remove the optional
device from the exten-
sion and plug in an
optional device that you
know rings properly.
First, make sure the
standard device in the
combination is plugged
into the correct slot on
the 267F2 bridging
adapter (see Figure 2-5).
If the extension still does
not work properly,
unplug the adapter from
the wall jack. Unplug the
phone's cord from the
adapter and plug it
directly into the wall jack.
Re-enter the date, day,
and time using System
Programming (#101,
#102 and #103).
Plug into the correct jack
(see Figure 2-5 on page
2-7).
First, unplug the bridging
adapter from the wall
jack. Then, unplug the
system phone from the
adapter and plug it into
the wall jack.
If...
The ringer functions properly,
Trouble still appears,
The ringer functions properly,
Trouble still appears,
The phone works,
The phone does not work,
The display works,
The display still does not
work
The system phone works
properly,
The problem remains,
The system phone works
properly,
Then...
Problem is with
optional device. The
system is okay.
Go to Possible Cause 2.
Problem is in the
optional device. The
system is okay.
Go to Possible Cause 3.
There is a problem
with the other device
attached to extension
or bridging adapter.
Replace the other
device. If the problem
is still not fixed, call 1
800 628-2888.
Call 1 800 628-2888.
Problem is solved.
Follow procedure for
"Other Problems with
Phones," page C-7.
The problem is solved.
Go to Possible Cause 2.
Either the cord or the
adapter must be
replaced. (Use only
an AT&T 267F2
bridging adapter.)
Calll 1 800 628-2888
for details.
