Specifications
Capacities
System
8 outside lines via line jacks on
four 206 or 200 modules
24 extensions via extension jacks
on four 206 modules
1 loudspeaker paging system
1 audio source via Music-On-Hold
jack on processor module
2 doorphones, using 2 extension
jacks
Dimensions
Processor module
and Weights
206 module
(assembled,
200 module
approx.)
Backplane & cover 12"(D) x 19"(H) x 11"(W) or 30.5cm x 48.3cm x 27.9cm
MLC-6 phone
MLS-6 phone
MLS-12 phone
MLS-12D phone
MLS-34D phone
Switch
Full digital, nonblocking
Fabric
Electrical 10 Watts (35 BTUs/hour) per 200 module, normal and peak power consumption
65 Watts (225 BTUs/hour) per 206 module during normal operation
Specifications
100 Watts (350 BTUs/hour) per 206 module during peak power consumption
4 Amps peak current at full system capacity (processor module and four 206 modules)
4-day memory backup (96 hours)
*The two devices combined on an extension jack can be a system phone with a standard device, or two standard devices. DO NOT connect two
system phones to the same extension jack. If a device lists two RENs, use the higher number when adding up RENs.
206 Module
2 outside lines
6 extensions
200 Module
2 outside lines
11"(D) x 17"(H) x 1.5"(W) or 27.9cm x 43.2cm x 3.8cm
11"(D) x 17"(H) x 1.5"(W) or 27.9cm x 43.2cm x 3.8cm
11"(D) x 17"(H) x 1.5"(W) or 27.9cm x 43.2cm x 3.8cm
9.4"D) x 3.4"(H) x T(W) or 23.9cm x 8.6cm x 17.8cm
9.5"(D) x 5"(H) x 6.75"(W) or 24.1cm x 12.7cm x 17.1cm
9.5"(D) x 5"(H) x 6.75"(W) or 24.1cm x 12.7cm x 17.1cm
9.5"(D) x 5"(H) x 6.75"(W) or 24.1cm x 12.7cm x 17.1cm
9.7"(D) x 5.3"(H) x 10"(W) or 24.6cm x 13.5cm x 25.4cm
D
Extension Jack
Maximum 2 devices per exten-
sion jack, total REN on jack not to
exceed 2.0* (2 devices require
AT&T 267F2 bridging adapter)
System phone REN: 0 (zero)
No more than one system phone
per jack
For programming, a system
display phone must be con-
nected to Extension 10.
4.0 Ibs or 1.8 kgs
4.5 Ibs or 2.0 kgs
4.0 Ibs or 1.8 kgs
5.5 Ibs or 2.5 kgs
2.9 Ibs or 1.3 kgs
1.8 lbs or 0.8 kgs
2.0 Ibs or 0.9 kgs
2.1 Ibs or 1.0 kgs
2.6 Ibs or 1.2 kgs
Specifications D-1
