Table Of Contents - Structural Concepts Impulse Series Installation & Operating Manual

TABLE OF CONTENTS

OVERVIEW / TYPE / COMPLIANCE / WARNINGS / PRECAUTIONS / WIRING .............................
CUSTOMER CABINET PROVISIONS.....................................................................................
CLEARANCE AND AIR FLOW ...............................................................................................
VENTING INSTRUCTIONS FOR AIR INTAKE / EXHAUST (FOR ALL CASES) ..............................
INSTALLATION: SKID REMOVAL / LOWERING INTO COUNTER (BASE) / SEALING ...................
START-UP AND OPERATION / TEMPERATURE SETTINGS / THERMOMETER ..........................
MAINTENANCE FUNDAMENTALS: SHELF / SHELF REMOVAL / MINI-LED LIGHT FIXTURES ......
MAINTENANCE FUNDAMENTALS: T-8 LIGHT FIXTURES / KEY (FRONT ACCESS) ....................
MAINTENANCE FUNDAMENTALS: REMOVING REAR DOORS / HINGED DOOR .......................
MAINTENANCE FUNDAMENTALS: EVAPORATOR COIL FANS ACCESS AND REMOVAL ...........
REFRIGERATION FUNDAMENTALS: ACCESS TO CONDENSER COIL / SERVICING /
TEMPERATURE CONTROL MODULE ........................................................................
CONDENSATE PACKAGE EXPLODED PICTORIAL (APPLICABLE TO MODEL DGS48XXR) ........
CONDENSATE PACKAGE EXPLODED PICTORIAL (APPLICABLE TO DGS24XXR & DGS36XXR).
SERIAL LABEL LOCATION & INFORMATION LISTED / TECH INFO & SERVICE .........................
TROUBLESHOOTING (BY TRAINED SERVICE PROVIDERS ONLY) .........................................
TROUBLESHOOTING (BY TRAINED SERVICE PROVIDERS ONLY) - CONDENSING SYSTEM ....
TROUBLESHOOTING (BY TRAINED SERVICE PROVIDERS ONLY) - EVAPORATOR SYSTEM ....
CLEANING SCHEDULE ......................................................................................................
CAREL® TEMPERATURE CONTROLLER INFORMATION ......................................................
TECHNICAL SERVICE CONTACT INFORMATION & WARRANTY INFORMATION ......................
Model DGS2423R
Model DGS2430R
Model DGS3623R
Model DGS3630R
Model DGS4823R
Model DGS4830R
Note: Internal counter height must be at least 28" for refrigeration and proper air flow space.
Models DGS2423R & DGS2430R: Service Top Cutout dimensions must be 24.65" Long x 27.15" Deep (with a
minimum 1.42" perimeter) for proper clearance and fit of Drop-In Refrigerated Merchandiser. These combined
dimensions require a 30" minimum counter top space for cutout.
Models DGS3623R & DGS3630R: Service Top Cutout dimensions must be 36.65" Long x 27.15" Deep (with a minimum
1.42" perimeter) for proper clearance and fit of Drop-In Refrigerated Merchandiser. These combined dimensions require
a 30" minimum counter top space for cutout.
Model DGS4823R & DGS4830R: Service Top Cutout dimensions must be 48.65" Long x 27.15" Deep (with a minimum
1.42" perimeter) for proper clearance and fit of Drop-In Refrigerated Merchandiser. These combined dimensions require
a 30" minimum counter top space for cutout.
26 1/8"L x 28 5/8"D x 22 3/8"H (Upper Display Case Only)
26 1/8"L x 28 5/8"D x 46 3/4"H (Upper Display Case + Drop-In Refrigeration Unit)
26 1/8"L x 28 5/8"D x 29 3/8"H (Upper Display Case Only)
26 1/8"L x 28 5/8"D x 53 3/4"H (Upper Display Case + Drop-In Refrigeration Unit)
38 1/8"L x 28 5/8"D x 22 3/8"H (Upper Display Case Only)
38 1/8"L x 28 5/8"D x 46 3/4"H (Upper Display Case + Drop-In Refrigeration Unit)
38 1/8"L x 28 5/8"D x 29 3/8"H (Upper Display Case Only)
38 1/8"L x 28 5/8"D x 53 3/4"H (Upper Display Case + Drop-In Refrigeration Unit)
50 1/8"L x 28 5/8"D x 22 3/4"H (Upper Display Case Only)
50 1/8"L x 28 5/8"D x 46 3/4"H (Upper Display Case + Drop-In Refrigeration Unit)
50 1/8"L x 28 5/8"D x 29 3/4"H (Upper Display Case Only)
50 1/8"L x 28 5/8"D x 53 3/4"H (Upper Display Case + Drop-In Refrigeration Unit)
2
3-4
5
6
7
8
9
10
11
12
13
14
15
16
17
18-20
21
22
23-25
26
27
