Structural Concepts B3632H Installation And Operating Manual

Self-service, grab-n-go merchandisers / heated shelves / front control panel / ceramic metal halide lights
Hide thumbs Also See for B3632H:
Table of Contents

Advertisement

Quick Links

M O B I L E
SELF-SERVICE, GRAB-N-GO
MERCHANDISERS / HEATED SHELVES /
FRONT CONTROL PANEL / CERAMIC
METAL HALIDE LIGHTS
Model B3632H
I:\Oper Manuals\Oasis\B2432H_B3632H_Heated_Grab-N-Go_20-44626.pub
READ AND SAVE THESE INSTRUCTIONS
INSTALLATION AND
OPERATING MANUAL
S E R I E S
888 E. Porter Road · Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 www.structuralconcepts.com
P/N 20-44626
Important! See Installation
Section Of This Manual For
Specifics On Confirming
Proper Placement of
"Danger-Hot" Labels on
Heated Shelves and Deck
Model B2432H
Rev B Date: 1.29.2015
