REFRIGERATION SLIDE-OUT EXPLODED PICTORIAL
CONDENSATE PACKAGE EXPLODED PICTORIAL (APPLICABLE TO DGS24XXR & DGS36XXR)
The following images show the various parts pertaining to condensate
package (slid directly out from lower section) to be serviced.
Condensing Coil (and
Internal Fan and Motor)
Receiver
Copper
Tubing
Evaporator Pan
[and Hot Gas Loop]
Compressor
Condensate
Package Pan
Filter Dryer
Flexible Hose
Connections
Sight Glass
16
