SERVICE DROP-IN REFRIGERATED MERCHANDISER
OPEN REFRIGERATED SELF-SERVICE MERCHANDISER
Model DO3637R
Model DO4837R
Model DO3623R
Model DO4823R
Note 1. Internal counter height must be at least 28" for refrigeration and proper air flow space.
Note 2. Model DO3637R & 3623R: Service Top Cutout dimensions must be 27.15" Wide x 36.65" Long
(with a minimum 1.42" perimeter) for proper clearance and fit of Drop-In Refrigerated Merchandiser.
These combined dimensions require a 30" minimum counter top space for cutout.
Note 3. Model DO4837R & DO23R: Service Top Cutout dimensions must be 27.15" Wide x 48.65"
Long (with a minimum 1.42" perimeter) for proper clearance and fit of Drop-In Refrigerated
Merchandiser. These combined dimensions require a 30" minimum counter top space for cutout.
L:\Inst & Oper Man\Oasis\DO(L)37R, DO(L)23R Operr Man 99574.pub
READ AND SAVE THESE INSTRUCTIONS
INSTALLATION &
OPERATING MANUAL
Model DO3637R
38 1/8"L x 28 5/8"D x 37 1/4"H (
38 1/8"L x 28 5/8"D x 61 1/8"H (
50 1/8"L x 28 5/8"D x 37 1/4"H (
50 1/8"L x 28 5/8"D x 61 1/8"H (
38 1/8"L x 28 5/8"D x 23 1/4"H (
38 1/8"L x 28 5/8"D x 47 1/8"H (
50 1/8"L x 28 5/8"D x 23 1/4"H (
50 1/8"L x 28 5/8"D x 47 1/8"H (
R
888 Porter Rd. Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 www.structuralconcepts.com
Upper Display Case Only)
Upper Display Case + Drop-In Refrigeration Unit)
Upper Display Case Only)
Upper Display Case + Drop-In Refrigeration Unit)
Upper Display Case Only)
Upper Display Case + Drop-In Refrigeration Unit)
Upper Display Case Only)
Upper Display Case + Drop-In Refrigeration Unit)
PN 99574
Model DO4837R
Rev F Date: 11.2.2006
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Structural Concepts DO3623R
Summary of Contents for Structural Concepts DO3623R
- Page 1 Model DO4837R 50 1/8”L x 28 5/8”D x 37 1/4”H ( 50 1/8”L x 28 5/8”D x 61 1/8”H ( Model DO3623R 38 1/8”L x 28 5/8”D x 23 1/4”H ( 38 1/8”L x 28 5/8”D x 47 1/8”H ( Model DO4823R 50 1/8”L x 28 5/8”D x 23 1/4”H (...
-
Page 2: Table Of Contents
CLEARANCE AND AIR FLOW ...………………………..…………………..…….…………...….. VENTING INSTRUCTIONS FOR AIR INTAKE / EXHAUST - DO3637R …………………….. VENTING INSTRUCTIONS FOR AIR INTAKE / EXHAUST - DO4837R …………………….. VENTING INSTRUCTIONS FOR AIR INTAKE / EXHAUST - DO3623R …………………….. INSTALLATION ……………………………………………………………………………………….. START-UP AND OPERATION ..……………………………………………………………………. -
Page 3: Overview And Warnings
OVERVIEW AND WARNINGS OVERVIEW • The Structural Concepts® Oasis® refrigerated self-service cases are designed to merchandise packaged products at 5° Celsius / 41° Fahrenheit or less product temperatures. • These cases should be installed and operated according to the following instructions to insure proper performance. -
Page 4: Customer Cabinet Provisions
CUSTOMER CABINET PROVISIONS Customer Cabinet Provisions • Customer provided cabinet must adhere to the minimum requirements in ANSI/UL Std. 471 and ANSI/NSF Std. 7. • Among the factors that are to be taken into consideration when judging the acceptability of a cabinet or similar enclosure are mechanical strength, resistance to impact, moisture-absorptive properties, flame resistance, resistance to distortion at temperatures to which the material may be subjected under conditions of use, and resistance to corrosion. -
Page 5: Clearance And Air Flow
CLEARANCE AND AIR FLOW Service Top Cutout Dimensions Note: See Manual Cover for DO3637R, DO4837R, DO3623R & 4823R Service Top Cutout Dimensions. Clearance Dimensions The Refrigerated section must maintain airflow clear- ance. Dimensions are as follow. 1. 4" Minimum Spacing from bottom of refrigeration frame to bottom of cabinet or floor required for ade- quate air flow. -
Page 6: Venting Instructions For Air Intake / Exhaust - Do3637R
VENTING INSTRUCTIONS FOR AIR INTAKE / EXHAUST - DO3637R CUSTOMER-SUPPLIED COUNTER/BASE Warning: The minimum intake and exhaust areas must be allowed (as illustrated below) or case temperatures may fluctuate beyond safe parameters. NOTES: BACK OF CABINET MUST BE VENTED A MINIMUM OF 13” x 13” FOR AIR INTAKE. BACK OF CABINET MUST BE VENTED A MINIMUM OF 10 1/2”... -
Page 7: Venting Instructions For Air Intake / Exhaust - Do4837R
VENTING INSTRUCTIONS FOR AIR INTAKE / EXHAUST - DO4837R Warning: The minimum intake and exhaust areas must be allowed (as illustrated below) or case temperatures may fluctuate beyond safe parameters. NOTES: 1. BACK OF CABINET MUST BE VENTED A MINIMUM OF 13” x 25” FOR AIR INTAKE. 2. -
Page 8: Venting Instructions For Air Intake / Exhaust - Do3623R
VENTING INSTRUCTIONS FOR AIR INTAKE / EXHAUST - DO3623R & DO4823R Warning: The minimum intake and exhaust areas must be allowed (as illustrated below) or case temperatures may fluctuate beyond safe parameters. NOTES: 1. BACK OF CABINET MUST BE VENTED A MINIMUM OF 10 1/2” x 11” FOR AIR INTAKE. -
Page 9: Installation
INSTALLATION 1. Remove Case From Skid Caution: Case must always remain supported or center of gravity may allow case to fall. Slide to rear of skid and tip backward off skid while maintaining support. See illustration below. Drop-In Refrigerated Section 3. -
Page 10: Start-Up And Operation
START-UP AND OPERATION Case Start-Up • Plug cord into a certified electrical outlet with ground. • Turn on the Main Power Switch. Switch is in the Drop-In Refrigerated Section on the rear right hand side of base. • The Temperature Control Module (LED) will illuminate. -
Page 11: Maintenance Fundamentals
MAINTENANCE FUNDAMENTALS Adjustable Shelf • Adjustment of the angle of the shelves can be made by pivoting the lower portion of the shelf bracket in the upright. • The shelves can be adjusted to an angle of: 0, 5, and 10 degrees. •... - Page 12 MAINTENANCE FUNDAMENTALS, CONTINUED Warning, disconnect power before provid- ing maintenance and service to unit. As- sembly or disassembly and servicing to be accomplished by licensed electrical con- tractor. Evaporator Coil Fans Access and Removal • Fans may be accessed by removing Deck (covering Fan Shroud, Fan Housing and Coil).
-
Page 13: Maintenance Fundamentals
MAINTENANCE FUNDAMENTALS, CONTINUED Removing the Rear Doors • Remove Thumbscrews (4 each side). Thumbscrew removal will allow Rear Doors to be removed. • See illustration on this page for locations of Thumbscrews, Nuts, Perforated Acrylic Plenum, etc. • Move the doors toward the center of the case. -
Page 14: Refrigeration Fundamentals
REFRIGERATION FUNDAMENTALS Refrigeration Access, Connections & Servicing Assembly or disassembly and servicing to be accomplished by licensed refrigeration contractor. • Refrigeration Unit slides directly out from lower section to allow for servicing. • Service connections are located in the Refrigeration Slide-Out (shown at right). •... -
Page 15: Refrigeration Slide-Out Exploded Pictorial
REFRIGERATION SLIDE-OUT EXPLODED PICTORIAL The following images show the various parts pertaining to the Refrigeration Unit (that is slid directly out from lower section) to be serviced. Condensing Coil Electrical (and internal fan) Junction Box Refrigeration Service Valve Capacitor Sight Glass Condensate Receiver Copper... -
Page 16: Technical Information Sheet - Model Do3637R
TECHNICAL INFORMATION SHEET - MODEL DO3637R 888 Porter Rd. Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 www.structuralconcepts.com... -
Page 17: Technical Information Sheet - Model Do4837R
TECHNICAL INFORMATION SHEET - MODEL DO4837R 888 Porter Rd. Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 www.structuralconcepts.com... -
Page 18: Technical Information Sheet - Model Do3623R
TECHNICAL INFORMATION SHEET - MODEL DO3623R 888 Porter Rd. Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 www.structuralconcepts.com... -
Page 19: Technical Information Sheet - Model Do4823R
TECHNICAL INFORMATION SHEET - MODEL DO4823R 888 Porter Rd. Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 www.structuralconcepts.com... -
Page 20: Troubleshooting
TROUBLESHOOTING Product is Drying Out Water on the Floor Excessive Fan Noise System is not Operating Fans Not Working Case Lights Not Working Condensing Unit Not Operating. Check the relative humidity in the store. Check that all of the hoses are connected. Check that the drain trap is free of debris. -
Page 21: Troubleshooting
TROUBLESHOOTING, CONTINUED Alarm Going Off, CPC ESC3 Not Holding Temperature. E0 flashing, Air probe has failed. E1 flashing, Defrost termination or product probe has failed. L0 flashing, Low temperature alarm. H1 flashing, High temperature alarm. Ed flashing, Defrost timeout has occurred (did not terminate correctly). -
Page 22: Cleaning Schedule
CLEANING SCHEDULE Cleaning Clean Case Exterior Clean Case Interior Daily Weekly Monthly Clean outside surface of front curved glass with a household or commercial glass cleaner. Clean wood, laminate and painted surfaces with a mild soap and water solution and a soft cloth . -
Page 23: Cpc® Esc3 Controller Overview
CPC® CONTROLLER - OVERVIEW Controller Overview The CPC® ESC3 series is an electronic refrigeration controller that provides control of compressor, fan and defrost management. The ESC3 provides control of a compressor (or solenoid) valve in re- sponse to temperature variations. Temperature Control Temperature control in the ESC3 is accomplished by comparing the temperature reading of the case temperature probe against the temperature set point. -
Page 24: Cpc® Esc3 Controller Operation
CPC® - ESC3 CONTROLLER OPERATION Interface - The ESC3 features a 3 digit LED display that shows the case temperature. Alternately, the display can be configured to display the product temperature if a product temperature probe is connected. The temperature can be displayed in either Alarm Key - The Alarm key illuminates when the controller has detected an alarm condition. -
Page 25: Cpc® Esc3 Set Point Changing Instructions
CPC® ESC3 SET POINT CHANGING INSTRUCTIONS Viewing and Changing the Temperature Set Point The temperature set point is the comparison point for the control temperature input. To change the set point value: 1. Press the Alarm key for 3 seconds, until the set point is displayed and blinking. 2. -
Page 26: Warranty
WARRANTY All sales by Structural Concepts Corporation (SCC) are subject to the following limited warranty. “Goods” refers to the product or products being sold by SCC. Warranty; Remedies; Limitations. SCC warrants that if any Goods are found by an authorized representative of SCC not to be of good material or workmanship within one year of the date of shipments SCC will, at its option after inspection by an authorized representative, replace any defective Good or pay the reasonable cost of replacement for any such defective Goods, provided that written notice of the defect is given to SCC within 30 days of the appearance of such defect. -
Page 27: Technical Service
TECHNICAL SERVICE TECHNICAL SERVICE DEPARTMENT 1.800.433.9489 888 Porter Rd. Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 www.structuralconcepts.com...
