4.3 Installing the components

4.3.1 Locking device

4.3.2 Block lock components

4.3.2.1 Deactivation unit
(Manual)
Install the locks as usual (see respective manual/brief instructions).
Observe the installation direction.
The block lock components are mounted in the protected area.
IMPORTANT
Electromagnetic interference
Digital components that are nearby can interfere with the activation units.
Install the activation units at least 1.5 m away from other digital

components.
1. Unscrew the slotted screws.
2. Remove the cover.
3. Secure the component with two countersunk screws (ø 3.5 mm x 30
mm) and two dowels (S5).
The countersunk screws and the dowels are not included in the scope
of delivery.
Install the deactivation unit directly next to the lock. This ensures optimum
radio communication.
Locking device
Locking cylinder

SmartHandles

SmartRelay
Use with locking cylinders
Align the deactivation unit so that the two fastening screws are in a
horizontal line (see drawing). The antennas then point directly at the
locking cylinder.
4. Initial operation
Distance
max. 30 cm
20 cm to 1 m
