4.2.1 Testing the deactivation unit

4.2.2 Testing the activation master

(Manual)
1. Connect the deactivation unit to a power supply (for example a 9V
block battery, see
2. Position the deactivation unit next to the digital locking device (lock cyl-
inder and SmartHandles max. 30 cm, SmartRelay 20 cm to 1 m).
3. Make sure that both the deactivation unit and its associated lock are
correctly programmed (see
4. Connect pins 13 and 15 (temporarily).
Lock is deactivated (beep at lock if necessary).
9
LED on deactivation unit goes out.
9
9 Lock no longer reacts to identification media.
5. Disconnect pins 13 and 15 again.
Locking device is activated (if necessary, signal tone on lock).
9
9 LED on deactivation unit goes on.
Lock reacts to identification media again.
9
6. Repeat the test several times.
7. Then carry out the installation as described (see
ents [ 19] Connecting the components [
and
}
1. Connect the activation master to a power supply (for example a 9V
block battery, see
2. Connect the external separate antenna if you want to use it later (see
Connections of the activation master [
3. Make sure that all components are correctly programmed (see
gramming [ 14] ).
}
4. Set jumper B1 to b/c (right).
5. Press the transponder authorised on the activation master twice briefly
(0.5 s to 2 s) within range of the activation master (with external an-
tenna: 1 cm to 3 cm).
The range of the antenna is restricted in VdS-compliant operation by
the aluminium sleeve.
The relay switches and connects pins 5 and 7 (alarm system would
9
now be activated).
Activation master beeps for 2.5 s.
9
6. Check whether the relay has switched.
7. Press the transponder authorised on the activation master twice briefly
again (0.5 s to 2 s) within range of the activation master (with external
antenna: 1 cm to 3 cm).
9 The relay switches and separates pins 5 and 7 (alarm system would
now be deactivated).
9 Activation master beeps twice (short-long).
Connections of deactivation unit [
Programming [
Connections of the activation master [
31]
}
4. Initial operation
27] ).
}
14] ).
}
Installing the compon-
25]
).
}
31] ).
}
).
Pro-
17 / 52
