VdS Block lock

4.2 Test before assembly/installation

(Manual)
Programming a block lock
NOTE
Auxiliary voltage for components
The components require a supply voltage during programming.
Connect a power supply to the components (for example a 9 V

Connections of deactivation unit [
battery), see
of the activation master [
[ 37] ).
}
Do not connect components to each other with wires.
ü
1. Only connect the component that you are about to program to the
power supply.
2. Select the component in the locking plan.
3. Click on the button
9 Window "Programming Lock" opens.
4. Click on the button Programming .
9 Window "Programming" opens.
9 The programming procedure is executed.
The window "Programming" closes.
9
5. After programming, via | Programming | select the entry Read high-
lighted locking device/set time .
9 Window "Read lock" opens.
6. Click on the button Read .
Window "Programming" opens.
9
9 Readout is performed.
Result is displayed.
9
9 If the component was read out successfully, it is programmed.
Repeat the programming for all other components.
You can also read the block lock components like other locking devices.
When reading out the devices are displayed as follows:
Activation master as activation master

Deactivation unit as deactivation unit

Activation slave as control unit

31] Connections of the activation slave
or
}
.
4. Initial operation
16 / 52
block
DC
27] Connections
