C 2
HAPTER
• Install the GPS receiver in the recommended location. Refer to the following table for the machine-specific
antenna mounting location.
NOTE: If your machine is not listed, install the receiver on the front-center of the cab.
Machine Preset
Case IH SPX 4430 2014
• Ensure the machine's hydraulic filters have been recently changed and there are no issues with the machine's
hydraulic system (e.g., pump issues, faulty hydraulic motors, fine metal deposits in the hydraulic hoses, etc.).
• Ensure the machine's hydraulic system is using fresh oil and debris is flushed from the hydraulic hoses, valves,
and filters.
Raven Industries recommends the following best practices when installing the SmarTrax system:
• Use part numbers to identify the parts.
• Do not remove the plastic wrap from a part until it is necessary for installation.
• Do not remove plastic caps from a part until it is necessary for installation.

POINT OF REFERENCE

The instructions in this manual assume that you are standing behind the machine, looking toward the cab.

UPDATES

Software and manual updates are available on the Raven Applied Technology website:
4 Case IH Patriot 4440, Model Year 2017 & Newer - Steering Ready SmarTrax™ Installation Manual
(from the rear wheel
Receiver X Position
(left to right)
Receiver position on
Centered
http://www.ravenhelp.com
Receiver Y Position
axle to the GPS
the cab)
14.5 ft./4.42 m
Receiver Z Position
(ground to top of
GPS Receiver)
12 ft./3.66 m
