Raven SmarTrax Installation Manual

Case ih stx 275-450, new holland tj450
Hide thumbs Also See for SmarTrax:

Advertisement

Quick Links

Download this manual
SmarTrax™ Installation Manual
CaseIH STX 275-450 &
New Holland TJ 275-450

Advertisement

loading
Need help?

Need help?

Do you have a question about the SmarTrax and is the answer not in the manual?

Questions and answers

Related Manuals for Raven SmarTrax

Summary of Contents for Raven SmarTrax

  • Page 1 SmarTrax™ Installation Manual CaseIH STX 275-450 & New Holland TJ 275-450...
  • Page 2 GPS satellites, the OmniSTAR correction service or the WAAS correction service. Raven Industries accepts no responsibility for the use of the signal for other than the stated purpose. Raven Industries shall not be responsible or liable for incidental or consequential damages or a loss of anticipated benefits or profits, work stoppage or loss or impairment of data arising out of the use, or inability to use, the SmarTrax or any of its components.
  • Page 3 Manual # 016-0190-004 H A P T E R NTRODUCTION Congratulations on your purchase of the Raven SmarTrax system! This system is designed to provide cutting-edge, hands-free steering of your machine via GPS coordinates. CaseIH STX450 Tractor New Holland TJ450 Tractor...

  • Page 4: Basic Kit

    CaseIH STX275-450/New Holland TJ275-450 SmarTrax Installation Manual Below you will see the kit contents that you should have received with this SmarTrax kit. Basic Kit Contents Quantity Item Description Part Number YAW SENSOR 063-0172-684C BRKT., MTG., SMARTRAX CONT., CASEIH SURVEY107-0171-703 CABLE, 20', HYD/OVERRIDE, SMARTRAX, YAW SE115-0171-775 WELDMENT, BRACKET, HYD., BLOCK, NH TJ &...
  • Page 5 Caution must be exercised. Any work carried out on the hydraulic system must be performed in accordance with the machine manufacturerer’s approved maintenance instructions. Raven Industries recommends that appropri- ate protective equipment be worn when working on the hydraulic system. Ob- jects or materials that are able to bypass the machine’s hydraulic filtration system...
  • Page 6 CaseIH STX275-450/New Holland TJ275-450 SmarTrax Installation Manual We welcome your feedback about this manual. If you have any comments or Contacting suggestions for improvement, please let us know by contacting our Customer Raven Support Center by any of the following methods:...
  • Page 7 H A P T E R OUNTING THE NIVERSAL RACKET AND ALVE The SmarTrax Steering Assist Valve Bank and Steering Override Installing Pressure Switch are to be mounted on the supplied bracket. Steering Assist The mounting point for the Steering Assist Valve Bank & Steering Valve Bank &...
  • Page 8 CaseIH STX275-450/New Holland TJ275-450 SmarTrax Installation Manual Mounting location for Smartrax Valve Bank Steering Assist Valve Bank mounting location for New Holland TJ275-450 Series tractors. Steering Assist Valve Bank Mounting Bracket mounting point...
  • Page 9 Manual # 016-0190-004 Steering Control Unit (SCU) Port LS Port T Port R Port P Port L SCU ports before SmarTrax steering installation...
  • Page 10 CaseIH STX275-450/New Holland TJ275-450 SmarTrax Installation Manual Notes:...
  • Page 11 Steering Assist 1. The Tank hose (P/N 214-1000-025) should be the first hose to be Valve Bank connected. The tank hose connects to the T port on the SmarTrax valve. Hose Routing It then leads up towards the orbital where it will connect to the T port on the orbital using a supplied tee connector and reducer.
  • Page 12 Priority Valve. Disconnect this original LS hose only from the LS Port of the orbital. Remove fitting from the LS PV port on the SmarTrax block and install the supplied fitting. Connect the supplied LS-steer hose (P/N 214-1000-026) to the LS-Steer port on the SmarTrax Valve.
  • Page 13 Manual # 016-0190-004 The supplied Pressure hose (P/N 214-1000-025) connects to the P port of the SmarTrax Valve and leads up towards the orbital where it con nects to the Pressure port on the orbital using a supplied tee connector and reducer fitting.
  • Page 14 CaseIH STX275-450/New Holland TJ275-450 SmarTrax Installation Manual...
  • Page 15 ENSOR Mounting the Yaw Sensor Yaw Sensor Installing the Raven Yaw Sensor is quick and easy. Raven recommends that you keep the following points in mind while installing the sensor: Installation • The sensor is not weatherproof. Mount the sensor inside of the machine’s cab or drivers compartment.

  • Page 16: Wiring Connections

    CaseIH STX275-450/New Holland TJ275-450 SmarTrax Installation Manual Wiring Attach the wiring harness to the SmarTrax valve coil, pressure switch, and SPS. Route the harness into the cab, securing it away from moving parts and heat Connections sources. For more instructions, refer to the Universal Kit Manual. Be sure the rubber gasket is installed on the pressure switch connection.

  • Page 17: Start-Up Procedures

    Manual # 016-0190-004 H A P T E R TART- ROCEDURES After installing the SmarTrax on your machine, always follow these start-up procedures. Turn the wheels fully from side to side numerous times to remove air from the hydraulic system.
  • Page 18 CaseIH STX275-450/New Holland TJ275-450 SmarTrax Installation Manual Notes:...
  • Page 19 How Can I Get Service? Bring the defective part and proof of purchase to your Raven Dealer. If your Dealer agrees with the warranty claim, the Dealer will send the part and proof of purchase to their distributor or to Raven Industries for final approval.
  • Page 20 P.O. Box 5107 Fax: 605-331-0426 Sioux Falls, SD 57117-5107 www.ravenprecision.com atdinfo@ravenind.com Notice: This document and the information provided are the property of Raven Industries, Inc. and may only be used as authorized by Raven Industries, Inc. All rights reserved under copyright laws.
