Audio - Extron electronics TLI Pro 101 User Manual

Audio

Press
Audio
Status
Master
100
50
0
Figure 15.
Use the slider control to adjust the Master, Click, Sound, and HDMI In settings. The slider
adjusts the volume setting from 0 to 100% in 1% increments. By default all sliders are set to
80%.
Master volume sets the maximum volume for all the other sound volume settings. For
•
example, if the master volume is set to 80% (80 percent of maximum), and the the Sound
volume is set to 75%, the overall Sound volume is 60% of maximum (75% of 80%).
Click sets the level for audible feedback that accompanies events such as a screen
•
button being pressed.
Sound sets the audio level from any audio file playback.
•
HDMI sets the HDMI audio input level.
•
Underneath each slider control is the mute button, which toggles the volume between audio
mute and the value set by the corresponding slider. When the Master volume is muted, all
other settings (Click, Sound, and HDMI) are also muted.
in the navigation panel to open the
Network Output
Audio
Click
100 100
50
0
Audio Screen
screen.
Audio
Input Advanced
Exit
Sound HDMI
100
50 50
0 0
TLI Pro 101 • On-screen Menus 18
