Sleep timer
The Sleep Timer can be toggled between
If the sleep timer is
, after a period of inactivity, the screen goes dark to save power
On
•
(Sleep mode). Use the up and down arrows to set how long the period of inactivity should
be. The value can be between 1 and 120 minutes.
If the sleep timer is
Off
, the panel does not enter sleep mode.
•
Display timer
The Display Timer can be toggled between
panel is inactive before the output sync is disconnected.
To deactivate the display timer, click
•
out.
To set the display timer, ensure the function is activated by clicking
•
The value can be between 1 and 120 minutes.
NOTES:
•
When the sleep timer is used to deactivate the screen, the screen goes dark, which
provides partial energy savings. The screen reactivates quickly when it is touched.
•
When the display timer is used to deactivate the screen, the output sync is
disconnected and the screen switches off. This provides better energy savings but the
screen takes longer to reactivate when it is touched.
Test patterns
The TLI Pro 101 provides eight test patterns, which can be used to
calibrate the third-party touchpanel display. Click the
open the test pattern menu.
Color Bars
Crosshatch
Ramp
Alt Pixels
When pattern is open:
Swipe screen for next pattern.
Tap screen to exit.
Figure 14.
Test Pattern Menu
1.
Select the test pattern you need by pressing the icon.
2.
Swipe the screen from left to right to show the previous test pattern or swipe the screen
from right to left to show the next test pattern.
3.
Touch any part of the screen to show the menu box.
4.
Click
Exit
to close the
Test Patterns
and
.
On
Off
and
. If it is
On
Off
. The controls for the
Off
button to
Show
Crosshatch 4x4
Grayscale
White Field
Crop
Exit
dialog and return to the
TLI Pro 101 • On-screen Menus
, it determines how long the
On
are grayed
Display Timer
. Adjust the time.
On
Test Pattern
Show
Output
window.
17
