Extron electronics TLI Pro 201 Setup Manual

TLI Pro 201 • Setup Guide
Overview
The Extron TLI Pro 201 is a TouchLink
within an Extron Pro series control system. The scaled output supports resolutions up to 4K @ 30 Hz. The Extron TLI Pro 201 also
provides annotation features that allow users to draw, point, or type on video sources during presentations.
This guide provides instructions for experienced installers to mount and install the TLI Pro 201 and to create a basic configuration.
For more complete instructions, see the TLI Pro 201 User Guide, at www.extron.com.
Setup Checklist
Get Ready
… Download and install the latest version of the following software:
Toolbelt — Provides device discovery, device information, firmware updates, and configuration of network settings,
…
system utilities, and user management for TouchLink Pro devices.
… GUI Designer — For designing layouts for third party touchpanel interfaces.
… Global Configurator
processor and interface.
Global Scripter
…
NOTE: All four software programs are available from www.extron.com.
… Obtain the following network information from your network administrator:
… DHCP status — (on or off). If DHCP is off, you must also obtain:
IP address
…
… Usernames — These must be either
Password — The factory configured passwords for all accounts on this device have been set to the device serial
…
number. Passwords can be changed during configuration. They are case sensitive.
NOTE: If the device is reset to default settings, the passwords are reset to the default password, which is
(for either
Make a note of the MAC address for the TLI Pro 201.
…
Mount and Cable All Devices
… Mount the units. Place the TLI Pro 201 on a convenient surface, mount it in a standard rack, or use an under-table mounting
kit (see the TLI Pro 201 User Guide, at www.extron.com). To mount the third-party touchscreen follow the instructions
provided by the manufacturer.
… Connect cables to the TLI Pro 201 (see
… Connect the required HDMI source to the HDMI input of the TLI Pro 201.
… Connect the HDMI output from the TLI Pro 201 to the third-party touchpanel.
… Connect the USB port from the TLI Pro 201 to the third-party touchpanel.
NOTE: The USB connection passes information to the TLI Pro 201 about where on the screen the touchpanel was
pressed. If you are using a non-touch display, connect a USB mouse to the USB port on the TLI Pro 201 to click
the screen icons.
… Connect the Ethernet cable. The TLI Pro 201 must be powered by PoE+.
ATTENTION:
Do not power on the TLI Pro 201 until you have read the Attention in the Rear Panel Features section of the
•
TLI Pro 201 User Guide.
Ne branchez pas le TLI Pro 201 avant d'avoir lu la mise en garde dans la section « Rear Panel Features » du
•
TLI Pro 201 User Guide.
Interface scaler that integrates a third-party touchscreen display as a point of control
®
Professional and Global Configurator Plus — For setting up and configuring the control
®
— Provides an integrated development environment for Extron control systems programming.
®
Subnet mask
…
admin
admin user
or ).
Rear Panel Connectors and Features
Gateway
…
user
or .
Product Category
on the next page).
