Adding a channel

E ® T
NVOY RANSCEIVER
NOTE:
For detailed connection diagrams, please see the
Reference Manual (Codan part number
15-04176-EN issue 7).
To set the types of connections:
Do one of the following:
1
• If at least one connection between the control point
and the RFU uses an Ethernet cable, press
(Yes), then continue from
page
• If all connections between the control point and the
RFU use Codan control cables, press
then continue from
NOTE: This step in the wizard is shown if you are permitted
to add channels.
To add a channel:
Press (Yes) to add a channel, if required.
1
Enter the name that you want to use for the channel.
1
Press to move to the Tx entry.
1
Enter the transmit frequency that you want to use for this
1
channel (in kHz, with up to three decimal points or 1 Hz
resolution).
to move to the Rx entry.
Press
1
The Rx entry is automatically filled with the transmit
frequency.
Enter the receive frequency (in kHz, with up to three
1
decimal points or 1 Hz resolution), if required to be
different from the Tx frequency.
Press to move to the Mode entry.
1
G S G
ETTING TARTED
19.
Adding a channel on page
UIDE
U
SING THE WIZARD
U
SING THE WIZARD
Adding a channel on
(No),
19.
19
