Cables in a fixed station

Table 10: Cables for a typical fixed Envoy® station
Cable
Cable between RFU and 2230 Desk Console
Handset and speaker connector and cable
(optional)
Coaxial cable between RFU and antenna
Mounting a fixed Envoy® station

RFU and transceiver supply

E ® T
NVOY RANSCEIVER
NOTE: Cable 08-06022-001 is a 6 m cable only. Cable
08-01503-006 is a 6 m cable and is available in a
number of shorter and longer lengths.
A fixed Envoy® station uses a 2230 Desk Console. For general
guidance on suitable locations for equipment and installing the
fixed station see the reference material on the enclosed CD.
The RFU and the transceiver supply are self-contained and are
usually stacked loosely. If you want to mount the RFU and/or the
transceiver supply, contact your Codan representative to obtain a
rack-mounting unit or the appropriate mounting cradles.
CAUTION: If you are mounting an RFU in a cradle, do not fit
rubber feet to the bottom of the RFU.
NOTE: If you are transferring a mobile station to a fixed
station, and you are not mounting the RFU in a
cradle, rubber feet can be fitted to the bottom of the
RFU. The rubber feet are available from Codan
(Codan part number 30-11208-000).
G S G
ETTING TARTED
Symbol
UIDE
I
NSTALLING THE TRANSCEIVER
O
VERVIEW OF FIXED STATIONS
Part number
08-07205-xxx
08-06022-001
08-01503-006
185
