Earth symbols

RF earth connection points are provided on the Envoy transceiver
and 3020 Transceiver Supply. A protective earth is provided in the
AC mains wiring of the 3020 Transceiver Supply. This protective
earth must be connected at the AC mains supply outlet. The
symbols shown below are used to identify the earths on the
equipment.
Table 12:
200
Earth symbols
Symbol Meaning
Chassis earth
Protective earth
