E
® T
NVOY
RANSCEIVER
Your transceiver may have the option of selecting high, medium,
or low power, as set in Settings > Configuration > Tx Power.
By default, you can toggle between the Tx power settings by
pressing the 6 key. Hi, Med, or Lo is shown respectively to the
right of the signal strength indicator. If an external power amplifier
is connected, PA may also be selected.
While a call is being established, the transceiver shows that calling
activity is in progress by flashing
Once a call is established, these indicators are replaced with an icon
that represents the type of call being sent or received.
NOTE:
For detailed information on call types, please see the
Reference Manual (Codan part number
15-04176-EN issue 7).
Figure 7:
System lock and connected data application
icons
system lock
icon
When the transceiver is scanning, the channel screen is replaced by
the scanning screen.
G
S
G
ETTING
TARTED
in place of the scan indicator.
connected data
application icon
UIDE
O
PERATING THE TRANSCEIVER
T
HE CHANNEL SCREEN
33
