5.1.7 How do I change the module's IP address?

1 Use ProSoft Discovery Service to temporarily change a MVI56E module's
configuration port IP address.
2
Use ProSoft Configuration Builder to edit and download the Ethernet
configuration to the module.
3 Use the Optional Add-On Instruction (AOI). The AOI file is available on the
ProSoft Solutions CD-ROM, or can be downloaded from
www.prosoft-technology.com.
5.1.8 What is the purpose of the Optional MVI56E-MNETC Add-On
Instruction?
The Optional Add-On Instruction (AOI) allows the processor to perform the
following tasks:
1 Set the MVI56E Ethernet settings
2 Read the MVI56E Ethernet settings
3 Set MVI56E date/time information
4 Read the MVI56E date/time information
Items 1 and 2 can also be performed through ProSoft Configuration Builder
(PCB) for permanent IP address changes or through ProSoft Discovery Service
for temporary changes. Items 3 and 4 can also be performed through the
module's built-in web page.
The Optional AOI is needed only for specific applications where Ethernet or
CIPconnect access from a programmer's personal computer (PC) to the module
is not possible.

5.1.9 What is ProSoft Discovery Service (PDS)?

ProSoft Discovery Service (PDS) is Windows-based software that connects to
the Ethernet port of the module for the following purposes:
Automatic module discovery on the Ethernet network
Set a temporary IP address for the module for easy commissioning
Allow PCB to select the module for monitoring and IP address reconfiguration
The ProSoft Discovery Service software is supplied as a stand-alone utility, as
well as being integrated into PCB.

5.1.10 Does the MVI56E-MNETC module require processor logic?

Yes, ladder logic is required for data transfer between the MVI56E module and
the ControlLogix
For RSLogix™ 5000 version 16 applications (or later), the included Add-On
Instruction encapsulates the entire ladder logic into one single instruction.
For RSLogix 5000 version 15 and older, sample ladder logic is available from
the ProSoft Technology
Page 64 of 72
Modbus TCP/IP Multi Client Enhanced Communication Module
®
processor.
®
website at www.prosoft-technology.com.
