4.6.4 Enabling the MNET Client 0 Commands

The default module configuration contains two Modbus Client commands
associated to MNET Client 0. In the default configuration file, these commands
are disabled.
1 To enable the commands, expand the MVI56E-MNETC node in ProSoft
Configuration Builder until the MNET C
2 Double-click the MNET C
Client 0 Commands dialog box.
Select the first command in the list, and then click E
Important: The commands must also be enabled in the ladder logic in order for them to be
executed. The MNETC.CONTROL.CmdControl.WriteCmdBits[x] controller tag array holds 16-
command bit arrays for each Client. If a bit for a specific command is set to zero (0) in the
WriteCmdBits[x] controller tag, the command will not be executed, regardless of its enabled or
disabled state in the configuration.
Page 40 of 72
Modbus TCP/IP Multi Client Enhanced Communication Module
0 C
LIENT
0 C tag to open the Edit MNET
LIENT OMMANDS
MVI56E-MNETC ♦ ControlLogix Platform
tag is visible.
OMMANDS
R .
DIT OW
