MVI56E-MNETC ♦ ControlLogix Platform
Modbus TCP/IP Multi Client Enhanced Communication Module
2
In the Upload Files dialog box, click B
MNETC module. This action opens the ProSoft Discovery Service dialog box.
Select the module, and then click the right mouse button to open a shortcut
menu. On the shortcut menu, choose S
the module's Ethernet address in the Upload Files dialog box.
3
Click the X in the top right corner to close the ProSoft Discovery Service
dialog box.
4
In the Upload Files dialog box, click U
as shown in the following illustration, click the OK button.
ProSoft Configuration Builder now contains the sample configuration for your
MVI56E-MNETC module. In the following steps, you will configure the Read and
Write commands.
ProSoft Technology, Inc.
April 18, 2011
D
to locate the MVI56E-
ROWSE
EVICES
PCB. This action places
ELECT FOR
. When the upload is complete,
PLOAD
Procedures
Setup Guide
Page 39 of 72
