3.4

Memory Map

The memory map consists of the starting addresses for Read Data and Write
Data areas in the MVI56E-MNETC module and in the Quantum processor. The
sample application reads and writes 10 words between the Modbus TCP/IP
Client and the Modbus TCP/IP Server.
The following table describes the memory map for data transfer between the
MVI56E-MNETC module and the Quantum processor.
Function
Read
Write
ProSoft Technology, Inc.
April 18, 2011
MVI56E-MNETC Database
Start Address (Client)
1000
0
Quantum Memory Start
Address (Server)
400801
400401
The Sample Application
Setup Guide
Word Count
10
10
