Before You Begin
Setup Guide
2.3

Sample Files

Note: This procedure requires RSLogix 5000 version 16 (or later), which supports Add-On
Instructions. For RSLogix version 15 (or older) applications, please refer to the MVI56E-MNETC
User Manual for information on how to use the sample ladder logic.
The sample MVI56EMNETC_AddOn_Rung_v1_5.L5X Add-On Instruction file
contains all elements required for the MVI56E-MNETC module to function.
User-defined Data Types (UDTs)
Add-On Instruction (AOI)
Ladder rung with AOI
Controller tags
Item
MVI56EMNETC_AddOn_Rung_v1_5.L5X
Copy the file from the ProSoft Solutions CD-ROM, or download them from
www.prosoft-technology.com. Save it to a convenient location in your PC, such
as Desktop or My Documents.
Page 16 of 72
MVI56E-MNETC ♦ ControlLogix Platform
Modbus TCP/IP Multi Client Enhanced Communication Module
Description
Sample rung import file containing Add-On
Instruction
