4.10 Connecting the MVI56E-MNETC Module to the Modbus TCP/IP Server
The final part of this tutorial is to connect the supplied Ethernet cable to the
Ethernet Application Port on the MVI56E-MNETC module either directly, or
through an Ethernet hub or switch, to the Ethernet port on an NOE card in the
same rack with the Quantum processor.
The following illustration shows the Ethernet connection between the MVI56E-
MNETC module and the Quantum processor.
Page 54 of 72
MVI56E-MNETC ♦ ControlLogix Platform
Modbus TCP/IP Multi Client Enhanced Communication Module
ProSoft Technology, Inc.
April 18, 2011
