To use the CIPconnect Path Editor, follow these steps.
1 Configure the path between the 1756-ENBT connected to your PC and the
MVI56E-MNETC module.
If the module is located in a remote rack, add more racks to configure the
o
full path.
The path can only contain ControlNet or Ethernet/IP networks.
o
The maximum number of supported racks is six.
o
2 Click C
ONSTRUCT
3 Click OK to confirm the configured path.

4.8.2 Using RSWho to Connect to the Module

You need to have RSLinx installed on your PC to use this feature. You also need an ENBT module
set up in the rack. For information on setting up the ENBT module, see Using CIPconnect to
Connect to the Module (page 49).
1 In the tree view in ProSoft Configuration Builder, right-click the MVI56E-
MNETC module.
2 From the shortcut menu, choose D
3 In the Download dialog box, choose 1756 ENBT from the Select Connection
Type dropdown box.
ProSoft Technology, Inc.
April 18, 2011
CIP P
to build the path in text format
ATH
OWNLOAD FROM
PC D
.
TO EVICE
Page 51 of 72
