Prerequisites - ProSoft Technology inRAx MVI56E-MNETC Setup Manual

MVI56E-MNETC ♦ ControlLogix Platform
Modbus TCP/IP Multi Client Enhanced Communication Module
1.4

Prerequisites

To get the most benefit from this setup guide, you should have the following
skills:
Rockwell Automation
configure and transfer the Add-On Instruction to the processor
Microsoft Windows: install and launch programs, execute menu commands,
navigate dialog boxes and enter data.
Ethernet networking: connect the MVI56E-MNETC module to an Ethernet
network using a valid IP address and subnet mask
Hardware installation and wiring: install the module and safely connect
Modbus TCP/IP Client and ControlLogix devices to a power source and to the
MVI56E-MNETC module's Ethernet port
ProSoft Technology, Inc.
April 18, 2011
®
RSLogix™ 5000 software: launch the program,
Scope
Setup Guide
Page 11 of 72
