Required Items - ProSoft Technology inRAx MVI56E-MNETC Setup Manual

MVI56E-MNETC ♦ ControlLogix Platform
Modbus TCP/IP Multi Client Enhanced Communication Module
2.2

Required Items

This Setup Guide uses a sample application that shows you how to establish
communication between the MVI56E-MNETC module (Modbus TCP/IP Client)
and a Modbus TCP/IP Server device. The sample application requires the
following equipment.
Item
MVI56E-MNETC
1756-L63
1756-A7/B
1756-PA72/B
CPU434 12A
CPS 114 20
140XBP01000
140NOE77111
Ethernet cable
ProSoft Technology, Inc.
April 18, 2011
Description
Modbus TCP/IP Multi Client Enhanced Communication Module
ControlLogix processor
1 ControlLogix rack
1 ControlLogix rack power supply
Quantum processor (Modbus device)
Quantum power supply
Quantum rack
NOE Card
Ethernet cable to connect MVI56E-MNETC module to Ethernet network
for Modbus TCP/IP communication and diagnostics (supplied with the
module)
